Range Map

Origin: · two fingers to move map

×
1

Tank-dry, where fuel runs out at catalogue's stored cruise burn.

Excludes reserves: range beyond the dashed circle requires a leaner cruise than what we store. Great-circle, still air, book cruise. Estimates only: always verify against the POH.

Payload vs. Range

Occupants:

Fuel on board

Cargo

nm

Range

Cargo is additional payload after occupants and baggage.
full tanks
Available Range / nm
Mission capable. This load flies with full fuel.
Fuel reduced by . left aboard for nm range.
Over max payload by . At this load it cannot lift a single occupant.

Trip Preview

Mission Profile

Used market Only available used
459
KTAS
Cruise Speed
3,100
nm
Max Range
45,000
ft
Service Ceiling
11
Occupants
1,307
lbs
Wet Payload
Endorsements & ratings:
  • High-Altitude
  • Pressurization
  • Multi-Engine
  • Instrument
Bombardier Challenger 300 (N777MS, c/n 20168) at Las Vegas, January 2019. Photo: Tomas Del Coro, CC BY-SA 4.0.
Bombardier Challenger 300 (N777MS, c/n 20168) at Las Vegas, January 2019. Photo: Tomas Del Coro, CC BY-SA 4.0.

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

About the Bombardier Challenger 300

Type certificated 2003 Source: FAA Type Certificate Data Sheet

Overview

The Bombardier Challenger 300 is the super-midsize business jet that launched the BD-100 line, certified in 2003 and built through 2014, when the Challenger 350 replaced it. It established the formula the segment still runs on: a wide, stand-up cabin and transcontinental range, up to 3,100 nm, in an airframe smaller and cheaper to operate than the heavy jets above it. Two Honeywell HTF7000 turbofans, a 45,000 ft ceiling, and a Mach 0.82 cruise give it the altitude and speed of the class, and the type sold in volume, leaving a deep used market today.

For the buyer, the 300 is the value entry to the super-midsize cabin. It shares that cabin cross-section with the later 350 and 3500, so the passenger experience is much the same, and the airframe’s original selling point, short-field and hot-and-high performance, is intact. What it does not have is the 350’s later refinements: the canted winglets and more efficient HTF7350 engines that lifted the 350’s range, and the 2018 steep-approach certification that clears the 350 into London City. A 300 cannot fly that approach. The primary cross-shop is its own successor: stepping up to a Bombardier Challenger 350 buys winglets, steep-approach access, and a newer fleet for a higher price, while the 300 holds the lowest entry cost into the cabin. Against the Embraer Praetor 600, the newer Embraer offers fly-by-wire and more range that an early-2000s design cannot match. As with the rest of the family, full-fuel payload is tight, the 3,100 nm range and a full cabin are not the same flight.

Key Features for GA Buyers

  • The value entry to the super-midsize cabin. The 300 shares the wide BD-100 cabin cross-section with the 350 and 3500, but as the oldest and most numerous of the family it carries the lowest acquisition cost into that cabin.
  • Short-field and hot-and-high performance. Short takeoff and landing distances and good high-elevation performance were the 300’s original selling point.
  • A large, well-supported fleet. The 300 sold in volume across its 2003-2014 run, so parts, maintenance expertise, and resale activity are all plentiful.

Trade-offs

  • No winglets, no steep approach. The 300 predates the 350’s canted winglets, HTF7350 engines, and 2018 steep-approach certification; it gives up some range and efficiency to the 350 and cannot operate steep-approach fields such as London City.
  • An early-2000s design. Avionics and cabin systems are of the 300’s era; a buyer who wants current avionics is cross-shopping the 350, and one who also wants fly-by-wire the Embraer Praetor 600, not the 300.
  • Tight full-fuel payload. Like the rest of the family, filling the tanks leaves limited cabin payload, so the 3,100 nm range and a full cabin are not available on the same flight.

See Also

Technical Specifications

Dimensions & Weights

Wingspan 64 ft
Height
20 ft
Length
Source: FAA Type Certificate Data Sheet 69 ft
Parking area (ft²2)
5,446 ft²
Max Takeoff Weight
Source: FAA Type Certificate Data Sheet 38,850 lbs
Max Landing Weight
Source: FAA Type Certificate Data Sheet 33,750 lbs
Useful Load
15,350 lbs
Fuel Capacity
Source: FAA Type Certificate Data Sheet 2,096 gal

Performance

Cruise Speed
Source: manufacturer figure 459 KTAS
Never-Exceed (VNE)
Source: FAA Type Certificate Data Sheet 320 KIAS
Max Structural Cruise (VNO)
Source: FAA Type Certificate Data Sheet 300 KIAS
Range
Source: manufacturer figure 3100 NM
Service Ceiling
Source: FAA Type Certificate Data Sheet 45,000 ft

Engines

Log in to view or request powerplant data.

Sources

Where the figures on this page come from. Bombardier Challenger 300 specifications are traced to published references; estimated values are flagged inline next to the figure.
