Beechcraft V35B Bonanza
Piston • single engine • Low Wing • Retractable gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Passengers
lbs
@ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range
/ nm
Mission capable —
Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required —
You'll need to leave gallons of fuel behind
( gal usable for nm range).
Over max gross weight —
Reduce payload by lbs
to safely operate this aircraft.
Mission Profile
172
KTAS
Cruise Speed
4
Occupants
824
nm
Max Range
850
lbs
Wet Payload
About the Beechcraft V35B Bonanza
Beechcraft V35B Bonanza
The Beechcraft Bonanza V35B (produced 1970–1982) is the final and most refined iteration of the iconic “V-tail” Bonanza line, which began with the original Model 35 in 1947. Famous for its distinctive tail surfaces (ruddervators), the V35B combines high speed, fuel efficiency, and a robust airframe, earning it a reputation as one of the finest single-engine touring aircraft ever built.
Key Features for GA Buyers
- Speed & Efficiency: With a cruise speed of ~172 knots, it outpaces many contemporaries, making it an excellent cross-country platform.
- Cabin Comfort: The cabin is known for high-quality interior finishes, good visibility, and ample width compared to competitors like the Mooney.
- Iconic V-Tail: The unique design reduces drag and weight compared to a conventional tail, contributing to its performance edge.
- Support: Excellent parts availability and a strong owner community (American Bonanza Society).
Trade-offs
- “The Doctor Killer”: Historically stigmatized due to high accident rates involving wealthy but inexperienced pilots, though this was largely addressed through training and structural reinforcements (tail cuffs).
- Ruddervator Maintenance: The V-tail control surfaces require specialized rigging and maintenance; parts (specifically magnesium skins) can be expensive or hard to find.
- Yaw Instability: Some passengers find the “Bonanza Boogie” (tail wag in turbulence) uncomfortable, though a yaw damper largely solves this.
Technical Specifications
Dimensions
- Wingspan
- 33.5 ft
- Length
- 26.4 ft
- Height
- 7.6 ft
Weights
- Max Takeoff Weight
- 3,400 lbs
- Max Landing Weight
- 3,400 lbs
- Useful Load
- 1,294 lbs
- Fuel Capacity
- 74 gal
Performance
- Cruise Speed
- 172 KTAS
- Range
- 824 NM
- Service Ceiling
- 17,500 ft
- Rate of Climb
- 1136 fpm
