Diamond DA50 RG
Piston • single engine • Low Wing • Retractable gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Mission Profile
About the Diamond DA50 RG
The Diamond DA50 RG is a five-seat, single-engine composite aircraft powered by a 300 hp Continental CD-300 turbodiesel engine. It features retractable landing gear, double-slotted flaps, and Garmin G1000 NXi avionics. With a maximum takeoff weight of 4,407 lb and a useful load of 1,232 lb, it holds 49 US gal of fuel and has an NBAA IFR range of approximately 754 nm (incl. 30 min reserve). It cruises at around 172 ktas (82 % power at 14,000 ft) and climbs at up to 780 fpm to a service ceiling of 20,000 ft. Stall speed in landing configuration is 58 kts CAS, and VNE is 181 kts. The DA50 RG was EASA-certified on September 9, 2020, and FAA-certified on July 25, 2023.
Technical Specifications
Dimensions
- Wingspan
- 44.0 ft
- Length
- 30.31 ft
- Height
- 9.69 ft
Weights
- Max Takeoff Weight
- 4,407 lbs
- Max Landing Weight
- 4,407 lbs
- Useful Load
- 1,232 lbs
- Fuel Capacity
- 49 gal
Performance
- Cruise Speed
- 172 KTAS
- Range
- 754 NM
- Service Ceiling
- 20,000 ft
- Rate of Climb
- 780 fpm
