Socata TB-20 Trinidad

Piston • single engine • Low Wing • Retractable gear

Range Visualization

Origin: · click map to move · nm at current load

Payload vs. Range

Customize assumptions

Avg. pax weight (lbs)

Default: 190 lbs (FAA standard)

Luggage per pax (lbs)

Default: 30 lbs

Passengers

lbs @ lbs / pax

Select payload

0 lbs

Fuel on board

gal

+ Weight

Range

Available Range / nm

Mission capable — Aircraft can handle the current load with full fuel tanks.

Fuel tradeoff required — You'll need to leave gallons of fuel behind ( gal usable for nm range).

Over max gross weight — Reduce payload by lbs to safely operate this aircraft.

Mission Profile

163

KTAS

Cruise Speed

Occupants

1110

Max Range

684

lbs

Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

About the Socata TB-20 Trinidad

The Socata TB-20 Trinidad is a four-to-five seat, single-engine aircraft known for its spacious and comfortable cabin, often compared to a luxury car interior. As a high-performance aircraft with retractable gear and a 250 HP Lycoming engine, it serves as an excellent cross-country tourer and IFR platform. Its wide, 50-inch cabin and gull-wing doors make for easy passenger loading and a comfortable ride.

Technical Specifications

Dimensions

Wingspan: 32.3 ft
Length: 25.46 ft
Height: 9.35 ft

Weights

Max Takeoff Weight: 3,086 lbs
Max Landing Weight: 3,086 lbs
Useful Load: 1,200 lbs
Fuel Capacity: 86 gal

Performance

Cruise Speed: 163 KTAS
Range: 1110 NM
Service Ceiling: 20,000 ft
Rate of Climb: 1200 fpm

Engines
