About the Socata TB-10 Tobago
Type certificated 1979 Source: FAA Type Certificate Data Sheet
Overview
The Socata TB-10 Tobago is a four/five-seat, fixed-gear, low-wing single built in France by Socata (now part of Daher), in production from 1979 into the early 2000s. It pairs a 180 hp carbureted Lycoming O-360-A1AD and a Hartzell constant-speed propeller with the wide TB-family cabin, and it earned a reputation as a wide-cabin touring and instrument trainer with a car-like interior and excellent visibility.
The Tobago sits in the middle of Socata’s piston TB line, above the 160 hp fixed-pitch TB-9 Tampico and below the 250 hp retractable Socata TB-20 Trinidad. It cross-shops against the Piper Archer II and the Diamond DA40, offering more cabin width than most four-seat trainers at the cost of a thinner US parts network. Choose the TB-10 when a wide, comfortable cabin and a stable IFR-training platform matter more than outright speed, and fixed-gear simplicity is preferred over the retractable Trinidad.
Key Features for GA Buyers
- Wide, comfortable cabin. The TB-10 shares the broad TB-family fuselage and large doors, giving more shoulder room than most four-seat trainers, with the sports-car-styled interior Socata was known for.
- 180 hp with a constant-speed prop. The carbureted Lycoming O-360-A1AD and Hartzell constant-speed propeller deliver an honest 127-knot cruise and a 2,000-hour TBO.
- Fixed-gear simplicity. No retraction system keeps maintenance and insurance below the retractable TB-20, and the handling suits primary and instrument training.
- Day and night IFR. Approved for day and night IFR with stable handling, the Tobago covers cross-country instruction and private touring on the same airframe.
Trade-offs
- Speed. At about 127 knots the Tobago trades cruise for cabin width and simplicity; a retractable on the same power will cruise faster.
- Parts and support. As a French-built type with a smaller US fleet, some airframe-specific parts can be slower and costlier to source than for a comparable Cessna or Piper. Identify a shop familiar with the type before purchase.
- Payload with full fuel. With four seats and 54 gallons of usable fuel, a full-fuel TB-10 is realistically a two-to-three-person airplane. Check the weight-and-balance of the specific aircraft before planning four adults and bags.
- Modest climb and ceiling. The naturally aspirated O-360 gives roughly 790 fpm initial climb and a service ceiling near 13,000 ft, adequate for the mission but not a high-density-altitude performer.
See Also
- Socata TB-20 Trinidad – the retractable, 250 hp big brother in the same TB family; faster and more capable, with higher running costs. Compare
- Piper Archer II – the classic 180 hp fixed-gear low-wing tourer and trainer; narrower cabin, larger US parts and support network. Compare
- Piper Cherokee Warrior II – a 160 hp fixed-gear trainer; slower and simpler, with a lower operating cost. Compare
- Diamond DA40 – a modern 180 hp composite single; faster and more efficient on a similar mission, with a tighter back seat. Compare
Technical Specifications
Dimensions & Weights
- Height
- 10 ft
- Length
- 25 ft
- Parking area (ft²2)
- 1,301 ft²
- Max Takeoff Weight
- 2,530 lbs
- Max Landing Weight
- 2,530 lbs
- Useful Load
- 890 lbs
- Fuel Capacity
- Source: FAA Type Certificate Data Sheet 54 gal
Performance
- Cruise Speed
- 127 KTAS
- Never-Exceed (VNE)
- Source: FAA Type Certificate Data Sheet 165 KIAS
- Max Structural Cruise (VNO)
- Source: FAA Type Certificate Data Sheet 128 KIAS
- Approach Speed
- 65 KIAS
- Stall, Clean (VS1)
- 63 KIAS
- Range
- 650 NM
- Service Ceiling
- 12,990 ft
- Rate of Climb
- 790 fpm
Engine
Log in to view or request powerplant data.
Sources
Where the figures on this page come from. Socata TB-10 Tobago specifications are traced to published references; estimated values are flagged inline next to the figure.
