Mooney M20K Encore
Piston • single engine • Low Wing • Retractable gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Passengers
lbs
@ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range
/ nm
Mission capable —
Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required —
You'll need to leave gallons of fuel behind
( gal usable for nm range).
Over max gross weight —
Reduce payload by lbs
to safely operate this aircraft.
Mission Profile
Endorsements & ratings:
- High-Performance
- Complex
176
KTAS
Cruise Speed
4
Occupants
985
nm
Max Range
505
lbs
Wet Payload
About the Mooney M20K Encore
The Mooney M20K Encore is the ultimate iteration of the ‘Mid-Body’ M20K fuselage, produced briefly in the late 1990s. It is essentially a modernized ‘252’ with a 220hp Continental TSIO-360-SB engine and a higher gross weight.
Key Features for GA Buyers
- Efficiency: Known for squeezing high cruise speeds (170+ kts) out of a relatively small 220hp engine.
- Turbocharged: The Encore is fully capable in the flight levels (up to FL250), making it an excellent cross-country IFR platform that can top weather.
- Payload Bump: Offers a significant useful load increase over the earlier M20K 231/252 models (approx. 200+ lbs more).
Trade-offs
- Cabin Size: As a mid-body Mooney, rear legroom is tighter compared to the Bravo or Ovation (Long Body).
- Complexity: Requires careful engine management and maintenance typical of turbocharged Continentals.
Technical Specifications
Dimensions
- Wingspan
- 36.1 ft
- Length
- 25.4 ft
- Height
- 8.33 ft
- Parking area (ft2)
- 1401.44 ft2
Weights
- Max Takeoff Weight
- 3,130 lbs
- Max Landing Weight
- 3,100 lbs
- Useful Load
- 955 lbs
- Fuel Capacity
- 75 gal
Performance
- Cruise Speed
- 176 KTAS
- Never-Exceed (Vne)
- 196 KIAS
- Max Structural Cruise (Vno)
- 174 KIAS
- Approach Speed
- 75 KIAS
- Stall, Clean (Vs1)
- 65 KIAS
- Range
- 985 NM
- Service Ceiling
- 25,000 ft
- Rate of Climb
- 1000 - 1300 fpm
- Takeoff over 50 ft obstacle
- 2,000 ft
- Landing ground roll
- 2,200 ft
