About the Luscombe 8
Type certificated 1939 Source: FAA Type Certificate Data Sheet
Overview
The Luscombe 8 stood apart from its 1940s rivals before it ever left the ground: where the Piper J-3 Cub, Aeronca, and Taylorcraft wore fabric over a steel-tube frame, the Silvaire was all-metal from firewall to tail. This entry takes the 65 hp 8A on the Continental A-65 as its reference point, the most common Silvaire on FAA TCDS A-694 (type-approved 1939) and the version a Sport Pilot can still fly today. On 65 horsepower it is quick for its class: a tight, clean two-seater that rewards a light hand and flatters a good landing.
Key Features for GA Buyers
- All-metal airframe: no fabric to recover every fifteen or twenty years, the single largest ownership-cost difference between the Silvaire and its fabric-covered contemporaries. A dry-kept aluminum Luscombe shrugs off decades that would age out a fabric ship.
- Fast for its horsepower: about 85 knots on 65 hp puts the 8A at the quick end of the 1940s two-seaters, and its all-metal skin runs cleaner than the fabric Aeronca and Taylorcraft on the same engine.
- Legacy Light-Sport eligible: at 1,260 lb gross the 8A qualifies for Sport Pilot operation on a driver’s license, a status the up-engined 1,400 lb 8E and 8F do not share.
Trade-offs
- Quick-footed on the ground: a short, stiff, narrow-track gear and light tail make the Silvaire less forgiving in a crosswind than a Cub; a tailwheel endorsement and current feet are not optional.
- Snug cabin and heel brakes: two adults sit close, and many 8As use heel brakes that take practice to master. Original cabin heat is token, so winter flying is a cold-weather-gear affair.
- Modest climb and ceiling: about 550 fpm up and a ~14,000 ft service ceiling; a hot, high, fully-loaded day wants a longer runway. Buyers wanting more can look to the up-engined 8E (85 hp C-85) and 8F (90 hp C-90), which trade the Light-Sport ticket for climb and cruise.
See Also
- Aeronca 11 Chief – the fabric side-by-side rival on the same 65 hp engine: friendlier ground manners, but a recover bill the all-metal Luscombe never sees. Compare
- Taylorcraft BC – another fabric side-by-side contemporary: lighter on the controls and cheaper to buy, slower and softer-skinned. Compare
- Cessna 120 – Cessna’s all-metal answer: the same metal-skin durability with a wider cabin and a gentler gear. Compare
- Cessna 140 – the 120’s flapped, better-equipped sibling: more comfort and system for more money. Compare
- Aeronca 7AC Champion – the tandem trainer benchmark of the era: you sit fore-and-aft, stick-and-rudder pure. Compare
Technical Specifications
Dimensions & Weights
- Height
- 6 ft
- Length
- 20 ft
- Parking area (ft²2)
- 1,125 ft²
- Max Takeoff Weight
- Source: FAA Type Certificate Data Sheet 1,260 lbs
- Max Landing Weight
- 1,260 lbs
- Useful Load
- Source: third-party reference 510 lbs
- Fuel Capacity
- Source: FAA Type Certificate Data Sheet 14 gal
Performance
- Cruise Speed
- Source: third-party reference 85 KTAS
- Never-Exceed (VNE)
- Source: FAA Type Certificate Data Sheet 126 KIAS
- Max Structural Cruise (VNO)
- Source: FAA Type Certificate Data Sheet 100 KIAS
- Approach Speed
- 60 KIAS
- Stall, Clean (VS1)
- Source: third-party reference 35 KIAS
- Range
- Source: third-party reference 182 NM
- Service Ceiling
- Source: third-party reference 14,000 ft
- Rate of Climb
- 550 fpm
Engine
Log in to view or request powerplant data.
Sources
Where the figures on this page come from. Luscombe 8 specifications are traced to published references; estimated values are flagged inline next to the figure.
