Legacy 500/Praetor 600

Turbofan • twin engine • Low Wing • Retractable gear

Range Visualization

Origin: · click map to move · nm at current load

Payload vs. Range

Customize assumptions

Default: 190 lbs (FAA standard)

Default: 30 lbs

Passengers
lbs @ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range / nm
Mission capable — Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required — You'll need to leave gallons of fuel behind ( gal usable for nm range).
Over max gross weight — Reduce payload by lbs to safely operate this aircraft.

Mission Profile

Endorsements & ratings:
  • High-Altitude
  • Pressurization
  • Multi-Engine
  • Instrument
466
KTAS
Cruise Speed
12
Occupants
4018
nm
Max Range
1968
lbs
Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

About the Legacy 500/Praetor 600

Overview

This page is the Embraer EMB-550 family hub: one type certificate that spans several distinct airplanes, all pioneers of full fly-by-wire in the midsize and super-midsize business-jet classes. Use it to find the right variant; its specifications mirror the current production flagship, the Praetor 600.

  • Legacy 500 – the original 2014 midsize jet, transcontinental range (about 3,125 nm).
  • Praetor 600 – the 2019 super-midsize development, intercontinental range (4,018 nm) on more fuel and full-rated engines.
  • Praetor 600E – the 2026 enhancement, the same performance as the 600 with a 4K “Smart Window” cabin and ROAAS.

The shorter-fuselage Legacy 450 and Praetor 500 share the design under the related EMB-545 type certificate.

Key Features for GA Buyers

Full fly-by-wire. The only family in these classes with full digital flight controls and active turbulence reduction, for a ride and workload profile unmatched by conventional designs.

Flat-floor stand-up cabin. A six-foot flat-floor cabin across the family, among the most spacious in the midsize and super-midsize markets.

Honeywell HTF7500E power. The same engine model across the line, rated at 6,540 lbf on the Legacy 500 and at full 7,528 lbf thrust on the Praetor.

Trade-offs

  • Range is the fork between them. If coast-to-coast US covers your flying, the Legacy 500 is the value entry; if you cross oceans, the Praetor 600 or 600E adds the fuel and thrust for intercontinental legs on the same airframe.
  • New versus in-production. The Praetor 600 is the airplane to shop today; the 600E’s enhancements arrive with deliveries around 2029, while the Legacy 500 lives on the used market.
  • A family page, not one airframe. Confirm exactly which variant a listing is before comparing prices or performance, since the three differ materially in range and value.

See Also

Technical Specifications

Dimensions

Wingspan
70.5 ft
Length
67.3 ft
Height
21.1 ft
Parking area (ft2)
5820.15 ft2

Weights

Max Takeoff Weight
42,857 lbs
Max Landing Weight
37,478 lbs
Useful Load
17,948 lbs
Fuel Capacity
2385 gal

Performance

Cruise Speed
466 KTAS
Never-Exceed (Vne)
320 KIAS
Max Structural Cruise (Vno)
320 KIAS
Approach Speed
107 KIAS
Stall, Clean (Vs1)
95 KIAS
Range
4018 NM
Service Ceiling
45,000 ft
Rate of Climb
4000 fpm
Takeoff over 50 ft obstacle
4,717 ft
Landing ground roll
2,165 ft

Engines
