Beech Super King Air 350
Turboprop • twin engine • Low Wing • Retractable gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Mission Profile
About the Beech Super King Air 350
The Beechcraft Super King Air 350 is a twin-engine turboprop produced by Beechcraft (now Textron Aviation) and is part of the King Air series. It is powered by two Pratt & Whitney Canada PT6A-60A engines, each rated at 1,050 shp. The typical cabin accommodates up to 11 passengers plus 2 crew. With a maximum takeoff weight of 15,000 lb, the 350 cruises at up to 312 ktas, can climb at up to 2,700 fpm, and has a range of about 1,806 nm. It features a service ceiling of 35,000 ft and a clean stall speed around 75 kt. Its low-wing design has a wingspan of 57 ft 11 in without winglets and a length of 46 ft 8 in. The Super King Air 350 is pressurized, retractable-gear, and widely used in both civil (VIP transport, cargo, medevac) and military (ISR, utility) roles. Useful load can be up to 7145LB on 350i variant.
Technical Specifications
Dimensions
- Wingspan
- 57.917 ft
- Length
- 46.7 ft
- Height
- 14.333 ft
Weights
- Max Takeoff Weight
- 15,000 lbs
- Max Landing Weight
- 15,000 lbs
- Useful Load
- 5,145 lbs
- Fuel Capacity
- 539 gal
Performance
- Cruise Speed
- 262 KTAS
- Range
- 1806 NM
- Service Ceiling
- 35,000 ft
- Rate of Climb
- 2700 fpm
