Range Map

Origin: → · two fingers to move map

+ cargo
×
1

Tank-dry, where fuel runs out at catalogue's stored cruise burn.

Excludes reserves: range beyond the dashed circle requires a leaner cruise than what we store. Great-circle, still air, book cruise. Estimates only: always verify against the POH.

Payload vs. Range

Occupants:

Fuel on board

Cargo

nm

Range

Cargo is additional payload after occupants and baggage.
full tanks
Available Range / nm
Mission capable. This load flies with full fuel.
Fuel reduced by . left aboard for nm range.
Over max payload by . At this load it cannot lift a single occupant.

Trip Preview

Mission Profile

Used market Only available used
196
KTAS
Cruise Speed
1,310
nm
Max Range
28,500
ft
Service Ceiling
9
Occupants
1,142
lbs
Wet Payload
Endorsements & ratings:
  • High-Performance
  • Complex
  • High-Altitude
  • Multi-Engine
Aero Commander 680FL Grand Commander (N199WM) at Grimes Field — Photo: redlegsfan21, CC BY-SA 2.0
Aero Commander 680FL Grand Commander (N199WM) at Grimes Field — Photo: redlegsfan21, CC BY-SA 2.0

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

Log in Sign up

About the Aero Commander 680FL

Type certificated 1963 Source: FAA Type Certificate Data Sheet

Overview

The Aero Commander 680FL, marketed as the Grand Commander, is the stretched, cabin-class evolution of the Aero Commander line. Type-certified in May 1963 under CAR 3, it added a 44-inch fuselage section forward of the front spar (with additional structural rework aft) over the 680F, plus a larger horizontal stabilizer, creating a true executive transport with a separate flight deck and high-density seating for up to nine passengers.

It is powered by twin supercharged, geared Lycoming IGSO-540-B1A engines (later production used the IGSO-540-B1C), each rated 380 hp at sea level and driving three-blade Hartzell propellers. The supercharger and reduction gear give the 680FL meaningful high-altitude capability and the cabin presence required for corporate or heavy-duty utility missions, at the cost of powerplant complexity. In Aero Commander’s final two production years (1968-69) the model was rebranded Courser Commander.

Key Features for GA Buyers

  • Massive Cabin. The 44-inch stretch produces a true aisle feel and executive club seating for up to nine passengers.
  • High-Wing Visibility. Passengers get an unobstructed view of the ground, and the low cabin floor with airstair door makes entry and exit exceptionally easy.
  • Rugged Heritage. Robust airframe used historically for executive transport, freight, and check hauling, with continuing manufacturer-successor support through Twin Commander Aircraft.
  • High-Altitude Performance. Supercharged engines allow efficient cruise in the mid-teen altitudes, above much standard GA weather, with a service ceiling around FL 200 typical of in-service operations.

Trade-offs

  • Engine Complexity. The geared and supercharged Lycoming IGSO-540s are sophisticated powerplants requiring meticulous pilot management; overhauls are expensive and shops familiar with the geared Lycoming family are increasingly scarce.
  • Operating Costs. Combined fuel burn often exceeds 40 GPH, and the maintenance load on the geared engines, hydraulics, and cabin systems put the 680FL firmly in the deep-pockets bracket.
  • Runway Requirements. Unlike the shorter Commanders, which retain STOL character, the 680FL at gross weight needs healthy runway, particularly when accelerate-stop is computed against the 8,500 lb MTOW.
  • Variant Confusion. Buyers should confirm exact model designation on the data plate: 680F, 680FL (stretched), 680FL(P) (stretched and pressurised), and the later Rockwell 685 (Continental-powered, pressurised) all carry similar marketing names but have meaningfully different airframe, engine, and pressurisation specifications.

See Also

Technical Specifications

Dimensions & Weights

Wingspan 50 ft
Height
14 ft
Length
41 ft
Parking area (ft²2)
2,755 ft²
Max Takeoff Weight
Source: FAA Type Certificate Data Sheet 8,500 lbs
Max Landing Weight
8,500 lbs
Useful Load
2,480 lbs
Fuel Capacity
223 gal

Performance

Cruise Speed
196 KTAS
Never-Exceed (VNE)
Source: FAA Type Certificate Data Sheet 250 KIAS
Max Structural Cruise (VNO)
Source: FAA Type Certificate Data Sheet 200 KIAS
Approach Speed
95 KIAS
Stall, Clean (VS1)
79 KIAS
Range
1310 NM
Service Ceiling
28,500 ft
Rate of Climb
252 - 1282 fpm
Takeoff over 50 ft obstacle
1,570 ft
Landing over 50 ft obstacle
2,343 ft

Engines

Log in to view or request powerplant data.

Log in Sign up

Sources

Where the figures on this page come from. Aero Commander 680FL specifications are traced to published references; estimated values are flagged inline next to the figure.
