About the Maule M-5
Type certificated 1976
Overview
The Maule M-5-235C Lunar Rocket is a four-seat STOL utility taildragger built by Maule Air of Moultrie, Georgia, and the high-power member of the M-5 family produced from 1976. A 235 hp Lycoming O-540 turning a Hartzell constant-speed propeller gives it a strong power-to-weight ratio on a light welded steel-tube-and-fabric airframe, the source of its short-field reputation. Oleo-strut tailwheel gear and a four-door cabin suit it to rough off-airport strips. The M-5 series also came in 180 hp and 210 hp versions; this record covers the 235C, its highest-horsepower variant.
Standard tanks hold about 43 gallons, good for roughly 360 nm with reserves; optional long-range tanks raise capacity toward 63 gallons and stretch that to about 480 nm. Against a metal hauler like the Cessna 180, the Maule trades cabin width and resale depth for a lighter airframe and shorter field performance. It is the aircraft for a backcountry or bush pilot who wants genuine STOL capability and field-repairable steel-and-fabric simplicity, and who will trade paved-runway refinement to get it.
Key Features for GA Buyers
- Short-field capability. Clears a 50 ft obstacle in about 600 ft, opening up mountain and backcountry strips.
- Four-door loading. Doors on both sides plus a dedicated cargo door ease loading of bulky gear such as skis or fishing equipment.
- Rugged structure. A welded steel-tube fuselage with fabric covering tolerates rough off-airport use and is field-repairable.
- Strong climb. Rated climb near 1,350 ft/min at gross weight.
Trade-offs
- Tailwheel and high-performance. Requires a tailwheel endorsement, and at 235 hp a high-performance endorsement as well.
- Cabin width. Narrower than a Cessna 182, with utilitarian fit and finish.
- Short-coupled handling. Like all short taildraggers, it needs active rudder during the takeoff and landing rolls.
- Standard fuel is modest. Standard tankage gives roughly 360 nm of range; the long-range tanks are worth seeking for serious cross-country use.
See Also
- Maule M-7 – the stretched five-seat successor in the same STOL family. Compare
- Cessna 180 Skywagon – classic metal backcountry hauler. Compare
- Piper PA-18 Super Cub – the benchmark STOL bush taildragger. Compare
- Aviat Husky – modern two-seat STOL utility taildragger. Compare
- Stinson 108 Voyager – postwar four-seat classic taildragger. Compare
Technical Specifications
Dimensions & Weights
- Height
- 6 ft
- Length
- 24 ft
- Parking area (ft²2)
- 1,163 ft²
- Max Takeoff Weight
- 2,300 lbs
- Max Landing Weight
- 2,300 lbs
- Useful Load
- 900 lbs
- Fuel Capacity
- 43 gal
Performance
- Cruise Speed
- 140 KTAS
- Never-Exceed (VNE)
- Source: FAA Type Certificate Data Sheet 156 KIAS
- Max Structural Cruise (VNO)
- Source: FAA Type Certificate Data Sheet 126 KIAS
- Approach Speed
- 60 KIAS
- Stall, Clean (VS1)
- 48 KIAS
- Range
- 360 NM
- Service Ceiling
- 20,000 ft
- Rate of Climb
- 1350 fpm
- Takeoff over 50 ft obstacle
- 600 ft
- Landing over 50 ft obstacle
- 600 ft
Engine
Log in to view or request powerplant data.
Sources
Where the figures on this page come from. Maule M-5 specifications are traced to published references; estimated values are flagged inline next to the figure.
