Blackshape Prime

Piston • single engine • Low Wing • Retractable gear

Range Visualization

Origin: · click map to move · nm at current load

Payload vs. Range

Customize assumptions

Default: 190 lbs (FAA standard)

Default: 30 lbs

Passengers
lbs @ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range / nm
Mission capable — Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required — You'll need to leave gallons of fuel behind ( gal usable for nm range).
Over max gross weight — Reduce payload by lbs to safely operate this aircraft.

Mission Profile

MOSAIC Eligibile Sport Pilot-flyable
Endorsements & ratings:
  • Complex
148
KTAS
Cruise Speed
2
Occupants
594
nm
Max Range
286
lbs
Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

About the Blackshape Prime

Overview

The Blackshape Prime (BK-100) is an Italian-designed, carbon-fiber masterpiece often referred to as the ‘Ferrari of the Sky.’ It features a tandem seating arrangement and retractable landing gear, offering a sleek, military-trainer aesthetic in a light sport or ultralight package. Primarily constructed from autoclave-cured pre-preg carbon fiber, it is exceptionally lightweight and rigid, allowing it to achieve high cruise speeds on a standard 100 hp Rotax engine.

Key Features for GA Buyers

  • Fighter-Like Experience: Tandem seating and a panoramic bubble canopy provide an immersive flight experience reminiscent of military aircraft.
  • Exceptional Efficiency: Achieving cruise speeds near 150 knots while burning only ~4.7-5 gallons per hour (Rotax 912ULS).
  • Advanced Construction: High-quality carbon fiber airframe is stressed to +4/-2g, providing responsive handling and modern durability.
  • Safety Systems: Often equipped with a Junkers ballistic recovery parachute system as standard or a common option.

Trade-offs

  • Payload Limitations: As a high-performance LSA/Ultralight, the useful load is tight; with two adults and full fuel, you are often right at the MTOW limits.
  • Complexity: The retractable landing gear and constant-speed propeller add maintenance requirements and insurance complexity compared to typical fixed-gear LSAs.
  • Tight Cabin: The 31-inch (80cm) wide cockpit is narrow, which may be uncomfortable for larger pilots during long cross-country flights.

Technical Specifications

Dimensions

Wingspan
26.05 ft
Length
23.56 ft
Height
7.91 ft
Parking area (ft2)
1029.59 ft2

Weights

Max Takeoff Weight
1,042 lbs
Max Landing Weight
1,042 lbs
Useful Load
388 lbs
Fuel Capacity
17 gal

Performance

Cruise Speed
148 KTAS
Never-Exceed (Vne)
165 KIAS
Max Structural Cruise (Vno)
148 KIAS
Approach Speed
54 KIAS
Stall, Clean (Vs1)
40 KIAS
Range
594 NM
Service Ceiling
15,000 ft
Rate of Climb
1150 fpm
Takeoff over 50 ft obstacle
985 ft
Landing ground roll
591 ft

Engine

Sign in to view or request powerplant data.
