Van's RV-14
Piston • single engine • Low Wing • Fixed gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Passengers
lbs
@ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range
/ nm
Mission capable —
Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required —
You'll need to leave gallons of fuel behind
( gal usable for nm range).
Over max gross weight —
Reduce payload by lbs
to safely operate this aircraft.
Mission Profile
Endorsements & ratings:
- High-Performance
170
KTAS
Cruise Speed
2
Occupants
815
nm
Max Range
510
lbs
Wet Payload
About the Van's RV-14
American two-seat aerobatic kit aircraft by Van’s Aircraft. Low-wing monoplane with fixed tricycle landing gear, powered by a 210 hp Lycoming IO-390 engine (optional 215 hp IO-390-EXP119 upgrade). Introduced July 2012; cruise 190 mph (170 kt), service ceiling 18 000 ft, range 815 nm.
Technical Specifications
Dimensions
- Wingspan
- 27.0 ft
- Length
- 21.1 ft
- Height
- 8.2 ft
- Parking area (ft2)
- 965.7 ft2
Weights
- Max Takeoff Weight
- 2,050 lbs
- Useful Load
- 810 lbs
- Fuel Capacity
- 50 gal
Performance
- Cruise Speed
- 170 KTAS
- Never-Exceed (Vne)
- 200 KIAS
- Approach Speed
- 80 KIAS
- Stall, Clean (Vs1)
- 62 KIAS
- Range
- 815 NM
- Service Ceiling
- 18,000 ft
- Rate of Climb
- 1800 fpm
