Piaggio Avanti EVO
Turboprop • twin engine • Mid Wing • Retractable gear
Range Visualization
Origin: · click map to move · nm at current load
Payload vs. Range
Customize assumptions
Default: 190 lbs (FAA standard)
Default: 30 lbs
Mission Profile
- High-Performance
- Complex
- High-Altitude
- Pressurization
- Multi-Engine
- Instrument
About the Piaggio Avanti EVO
The Piaggio Avanti EVO is a distinct and high-performing twin-turboprop. Its unique three-lifting-surface (canard, main wing, horizontal stabilizer) and rear-mounted pusher-propeller design provide jet-like speeds (up to 402 KTAS) and a remarkably spacious, stand-up cabin that rivals many light jets, all while offering the fuel efficiency of a turboprop. The EVO upgrade includes five-bladed scimitar propellers and winglets for reduced noise and improved performance. It is highly attractive to GA buyers needing a fast, long-range, and luxurious pressurized cabin aircraft for executive transport.
Technical Specifications
Dimensions
- Wingspan
- 47.06 ft
- Length
- 47.27 ft
- Height
- 13.06 ft
- Parking area (ft2)
- 2982.53 ft2
Weights
- Max Takeoff Weight
- 12,100 lbs
- Max Landing Weight
- 11,500 lbs
- Useful Load
- 4,250 lbs
- Fuel Capacity
- 415 gal
Performance
- Cruise Speed
- 402 KTAS
- Never-Exceed (Vne)
- 402 KIAS
- Max Structural Cruise (Vno)
- 350 KIAS
- Approach Speed
- 105 KIAS
- Stall, Clean (Vs1)
- 98 KIAS
- Range
- 1770 NM
- Service Ceiling
- 41,000 ft
- Rate of Climb
- 2770 fpm
