Grumman American AA5B
Piston single engine • Low Wing • Fixed gear
Range Visualization
Origin:
· nm at current load
· click map to move · two fingers to move map
Payload vs. Range
Configure weights
Default: 190 lbs
Default: 30 lbs
lbs
lbs / pax
Fuel on board
Extra weight
Range
Available Range
/ nm
Mission capable.
Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required.
You'll need to leave gallons of fuel behind
( gal usable for nm range).
Over max gross weight.
Reduce payload by lbs
to safely operate this aircraft.
Extra weight is the additional payload available with your selected passengers.
Mission Profile
139
KTAS
Cruise Speed
4
Occupants
554
nm
Max Range
588
lbs
Wet Payload
MOSAIC Eligible
Sport Pilot can fly
About the Grumman American AA5B
Overview
The Tiger is the definitive version of the AA-5. By combining the aerodynamic cleanups of the Cheetah with a 180 hp Lycoming O-360, Grumman created a fixed-gear aircraft that can outrun many retractable-gear competitors.
Key Features for GA Buyers
- High Performance (Non-Complex): Offers 140-knot cruise speeds without the maintenance headache or insurance premiums of retractable gear.
- Climb Performance: The extra 30 hp compared to the Cheetah makes it a much safer and more capable short-field and high-altitude performer.
- True 4-Seater: The 200 lb gross weight increase allows for a much more practical payload.
Trade-offs
- Purchase Price: Tigers command a significant premium over Travelers and Cheetahs—often $20k-$40k more for the same airframe age.
- Fuel Burn: Burns roughly 10-11 GPH compared to the 8-9 GPH of the 150 hp variants.
See also
Featured in our buying guides
Technical Specifications
Dimensions & Weights
- Height
- 8.0 ft
- Length
- 22.0 ft
- Parking area (ft2)
- 1118.34 ft2
- Max Takeoff Weight
- 2,400 lbs
- Max Landing Weight
- 2,400 lbs
- Useful Load
- 900 lbs
- Fuel Capacity
- 52 gal
Performance
- Cruise Speed
- 139 KTAS
- Never-Exceed (Vne)
- 174 KIAS
- Max Structural Cruise (Vno)
- 143 KIAS
- Approach Speed
- 75 KIAS
- Stall, Clean (Vs1)
- 56 KIAS
- Range
- 554 NM
- Service Ceiling
- 13,800 ft
- Rate of Climb
- 850 fpm
- Takeoff over 50 ft obstacle
- 1,550 ft
- Landing ground roll
- 1,120 ft
Similar to the Grumman American AA5B
Similar PistonsAero Commander 200
Cruise
183 kts (higher than this aircraft)
Range
900 nm (higher than this aircraft)
Seats
4
Beech 23 Sundowner
Cruise
118 kts (lower than this aircraft)
Range
565 nm (higher than this aircraft)
Seats
4
Beech 24 Sierra
Cruise
131 kts (lower than this aircraft)
Range
647 nm (higher than this aircraft)
Seats
4
See how the Grumman American AA5B stacks up against similar aircraft
