Beech 60 Duke

Piston • twin engine • Low Wing • Retractable gear

Range Visualization

Origin: · click map to move · nm at current load

Payload vs. Range

Customize assumptions

Default: 190 lbs (FAA standard)

Default: 30 lbs

Passengers
lbs @ lbs / pax
0 lbs
Fuel on board
gal
+ Weight
Range
Available Range / nm
Mission capable — Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required — You'll need to leave gallons of fuel behind ( gal usable for nm range).
Over max gross weight — Reduce payload by lbs to safely operate this aircraft.

Mission Profile

Endorsements & ratings:
  • High-Performance
  • Complex
  • High-Altitude
  • Pressurization
  • Multi-Engine
201
KTAS
Cruise Speed
6
Occupants
1015
nm
Max Range
1288
lbs
Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

Log in Sign up

About the Beech 60 Duke

The Beechcraft 60 Duke is a pressurized, twin-engine aircraft known for its sleek design and high performance for a piston twin. With turbocharged Lycoming engines, it offers good speed and the ability to fly comfortably at higher altitudes above weather. While known for higher maintenance costs compared to some contemporaries, it provides a fast, comfortable, pressurized cabin environment attractive for personal and business travel.

Technical Specifications

Dimensions

Wingspan
39.3 ft
Length
33.83 ft
Height
12.33 ft
Parking area (ft2)
1914.32 ft2

Weights

Max Takeoff Weight
6,775 lbs
Max Landing Weight
6,775 lbs
Useful Load
2,500 lbs
Fuel Capacity
202 gal

Performance

Cruise Speed
201 KTAS
Never-Exceed (Vne)
236 KIAS
Max Structural Cruise (Vno)
178 KIAS
Approach Speed
98 KIAS
Stall, Clean (Vs1)
73 KIAS
Range
1015 NM
Service Ceiling
30,000 ft
Rate of Climb
1601 fpm

Engines

Sign in to view or request powerplant data.

Log in Sign up

Similar to the Beech 60 Duke

Aero Commander 500 silhouette

Aero Commander 500

Cruise
178 kts (lower than this aircraft)
Range
955 nm (lower than this aircraft)
Seats
7
Piston twin engine High Wing
View details
Aero Commander 500A silhouette

Aero Commander 500A

Cruise
188 kts (lower than this aircraft)
Range
1564 nm (higher than this aircraft)
Seats
7
Piston twin engine High Wing
View details
Aero Commander 560 silhouette

Aero Commander 560

Cruise
182 kts (lower than this aircraft)
Range
1412 nm (higher than this aircraft)
Seats
7
Piston twin engine High Wing
View details
View all Piston aircraft

See how the Beech 60 Duke stacks up against similar aircraft
