Socata TBM-850

Turboprop • single engine • Low Wing • Retractable gear

Range Visualization

Origin: · click map to move · nm at current load

Payload vs. Range

Customize assumptions

Avg. pax weight (lbs)

Default: 190 lbs (FAA standard)

Luggage per pax (lbs)

Default: 30 lbs

Passengers

lbs @ lbs / pax

Select payload

0 lbs

Fuel on board

gal

+ Weight

Range

Available Range / nm

Mission capable — Aircraft can handle the current load with full fuel tanks.

Fuel tradeoff required — You'll need to leave gallons of fuel behind ( gal usable for nm range).

Over max gross weight — Reduce payload by lbs to safely operate this aircraft.

Mission Profile

320

KTAS

Cruise Speed

Occupants

1520

Max Range

894

lbs

Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

About the Socata TBM-850

The TBM 850, an upgrade to the TBM 700, is one of the fastest single-engine turboprops in the world. This aircraft has jet-like speeds (up to 320 KTAS) and highly efficient operating costs. It is powered by an 850 shp Pratt & Whitney PT6A-66D engine, but is limited to 700 shp for takeoff. It features a pressurized cabin, retractable gear, and advanced avionics (G1000 in later models), making it an attractive aircraft for corporate and private owners seeking speed, comfort, and long range for up to six people.

Technical Specifications

Dimensions

Wingspan: 41.75 ft
Length: 35.83 ft
Height: 14.33 ft

Weights

Max Takeoff Weight: 7,394 lbs
Max Landing Weight: 7,024 lbs
Useful Load: 2,777 lbs
Fuel Capacity: 281 gal

Performance

Cruise Speed: 320 KTAS
Range: 1520 NM
Service Ceiling: 31,000 ft
Rate of Climb: 2005 fpm

Engines
