Dornier Do 228

Turboprop twin engine • High Wing • Retractable gear

Range Visualization

Origin:

· nm at current load

· two fingers to move map

Payload vs. Range

Configure weights

Default: 190 lbs

Default: 30 lbs

Occupants
lbs lbs / pax

Fuel on board

Extra weight

Range

Available Range / nm
Mission capable. Aircraft can handle the current load with full fuel tanks.
Fuel tradeoff required. You'll need to leave gallons of fuel behind ( gal usable for nm range).
Over max gross weight. Reduce payload by lbs to safely operate this aircraft.
Extra weight is the additional payload available with your selected passengers.

Mission Profile

223
KTAS
Cruise Speed
19
Occupants
715
nm
Max Range
1264
lbs
Wet Payload

Estimated Ownership Costs

Create a free account to view or request ownership cost data.

Log in Sign up

About the Dornier Do 228

The Dornier 228 is the ultimate ‘Swiss Army Knife’ of the twin-turboprop world. Renowned for its extraordinary Short Takeoff and Landing (STOL) capabilities, it was designed with a unique supercritical wing (TNT - Tragflügel Neuer Technologie) that allows it to operate from short, unpaved, or high-altitude strips that would be impossible for other aircraft in its class. For the GA buyer or special missions operator, it offers unmatched versatility and a rugged, square-fuselage design optimized for cargo and utility.

Key Features for GA Buyers

  • STOL Performance: Can operate from runways as short as 2,500 ft at MTOW, making it a favorite for remote operations and island hopping.
  • Square Fuselage Design: The rectangular cabin cross-section maximizes usable space for cargo pallets or executive seating, providing more ‘shoulder room’ than oval-shaped competitors.
  • Large Cargo Door: Features a massive rear cargo door (standard on most variants) that allows for easy loading of bulky freight or medical stretchers.
  • Rugged Reliability: Designed for a 99% dispatch reliability, with a trailing-link landing gear that soaks up hits from unprepared surfaces.

Trade-offs

  • Unpressurized: Unlike its successor (the 328), the 228 is unpressurized. This limits its comfortable cruise altitude to 10,000–12,000 ft, though its service ceiling is much higher.
  • Noise Profile: The Garrett TPE331 engines are famously high-pitched and loud, both on the ramp and in the cabin, though 5-bladed composite props on the ‘NG’ models help significantly.
  • Speed: While fast for a utility aircraft, its 223-knot cruise is slower than dedicated executive turboprops like the Beechcraft King Air.

Technical Specifications

Dimensions & Weights

Wingspan 55.7 ft
Height
15.9 ft
Length
54.3 ft
Parking area (ft2)
3896.01 ft2
Max Takeoff Weight
14,110 lbs
Max Landing Weight
13,448 lbs
Useful Load
5,512 lbs
Fuel Capacity
634 gal

Performance

Cruise Speed
223 KTAS
Never-Exceed (Vne)
253 KIAS
Max Structural Cruise (Vno)
223 KIAS
Approach Speed
75 KIAS
Stall, Clean (Vs1)
80 KIAS
Range
715 NM
Service Ceiling
28,000 ft
Rate of Climb
1570 fpm
Takeoff over 50 ft obstacle
2,600 ft
Landing ground roll
1,480 ft

Engines

Sign in to view or request powerplant data.

Log in Sign up

Similar to the Dornier Do 228

Similar Turboprops

BAe Jetstream super 31

Cruise
230 kts (higher than this aircraft)
Range
680 nm (lower than this aircraft)
Seats
19
Turboprop twin engine Low Wing
View details

Beech 1900/C-12J

Cruise
280 kts (higher than this aircraft)
Range
1245 nm (higher than this aircraft)
Seats
19
Turboprop twin engine Low Wing
View details

Cessna 408 SkyCourier

Cruise
210 kts (lower than this aircraft)
Range
940 nm (higher than this aircraft)
Seats
19
Turboprop twin engine High Wing
View details
